Specifications:
Width:
- Minimum: 300mm
- Maximum: 4500mm
- Maximum Single Panel Width: 650mm (A 4mm width deduction is applied during manufacturing for recess fit shutters)
Drop:
- Minimum: 400mm
- Maximum: 2600mm (A 4mm drop deduction is applied during manufacturing for recess fit shutters)
Key Features:
- Constructed from PVC extrusion with a robust aluminium core
- Effortless operation with hand-operated 89mm 'easy-tilt' louvres
- Panels 1100mm and taller require a split tilt
- Panels 1400mm and larger necessitate midrails
Fitting Options:
- Suitable for both face and recess fitting (a recommended minimum window depth of 70mm for a flush recess fit)
- Customers are responsible for sourcing appropriate screws and additional materials tailored to their fitting surface
- Not suitable for shower recess fitting, as direct exposure to moisture can lead to hinge rust.
